Hydraulic Nuts

Hydraulic Nuts

The high-pressure driving force can be acquired by using hydraulic nut, so as to install bearing easily. In addition, through stable power transmission with piston, the installation will be more accurate. By using hydraulic nut, you can reduce the usage of clearance gauge.

More


ol ol
order number G thread d1 (mm) d2 (mm) d3 (mm) B (mm) B1 (mm) E piston permitted displacement (mm) piston area (mm2) weight (kg)
OS 040 M40x1.5P 41 75 103 38 4 6-10x12 5 3063 2.05
OS 045 M45x1.5P 46 80 108 38 4 6-10x12 5 3299 2.19
OS 050 M50x1.5P 51 85 113 38 4 6-10x12 5 3534 2.34
OS 055 M55x2.0P 56 90 118 38 4 6-10x12 5 3770 2.48
OS 060 M60x2.0P 61 95 128 38 5 6-10x12 5 4006 2.96
OS 065 M65x2.0P 66 100 133 38 5 6-10x12 5 4241 3.11
OS 070 M70x2.0P 71 105 138 38 5 6-10x12 5 4477 3.27
OS 075 M75x2.0P 76 110 143 38 5 6-10x12 5 4712 3.43
OS 080 M80x2.0P 81 115 148 38 5 6-10x12 5 4948 3.59
OS 085 M85x2.0P 86 120 153 38 5 6-10x12 5 5184 3.75
OS 090 M90x2.0P 91 124 158 38 6 6-10x12 5 5419 3.94
OS 095 M95x2.0P 96 129 163 38 6 6-10x12 5 5655 4.10
OS 100 M100x2.0P 101 134 168 38 6 6-10x12 5 5890 4.26
OS 105 M105x2.0P 106 139 173 38 6 6-10x12 5 6126 4.42
OS 110 M110x2.0P 111 144 178 38 6 6-10x12 5 6362 4.59
OS 115 M115x2.0P 116 149 183 38 6 6-10x12 5 6597 4.75
OS 120 M120x2.0P 121 159 188 38 6 6-10x12 5 8109 4.78
OS 125 M125x2.0P 126 164 193 38 6 6-10x12 5 8384 4.93
OS 130 M130x2.0P 131 169 198 38 6 6-10x12 5 8659 5.09
OS 135 M135x2.0P 136 174 203 38 6 6-10x12 5 8934 5.25
OS 140 M140x2.0P 141 179 208 38 6 6-10x12 5 9209 2.23
OS 145 M145x2.0P 146 184 213 38 6 6-10x12 5 9484 5.38
OS 150 M150x2.0P 151 189 218 38 6 6-10x12 5 9759 5.53
OS 155 M155x3.0P 156 194 223 38 6 6-10x12 5 10033 5.68
OS 160 M160x3.0P 161 199 232 41 7 6-10x12 6 10308 6.87
OS 165 M165x3.0P 166 204 237 41 7 6-10x12 6 10583 7.04
OS 170 M170x3.0P 171 211 242 41 7 6-10x12 6 10858 7.25
OS 180 M180x3.0P 181 221 252 41 7 6-10x12 6 11408 7.61
OS 190 M190x3.0P 191 231 262 42 7 6-10x12 7 11958 8.16
OS 200 M200x3.0P 201 247 272 43 7 6-10x12 7 12507 8.86
